Electric Circuits, Global Edition

Description
Table of Contents

The full text downloaded to your computer

With eBooks you can:

search for key concepts, words and phrases
make highlights and notes as you study
share your notes with friends

eBooks are downloaded to your computer and accessible either offline through the Bookshelf (available as a free download), available online and also via the iPad and Android apps.

Upon purchase, you'll gain instant access to this eBook.

Time limit

The eBooks products do not have an expiry date. You will continue to access your digital ebook products whilst you have your Bookshelf installed.

For courses in Introductory Circuit Analysis or Circuit Theory.

The fundamental goals of the best-selling Electric Circuits remain unchanged. The 11th Edition continues to motivate students to build new ideas based on concepts previously presented, to develop problem-solving skills that rely on a solid conceptual foundation, and to introduce realistic engineering experiences that challenge students to develop the insights of a practicing engineer. The 11th Edition represents the most extensive revision since the 5th Edition with every sentence, paragraph, subsection, and chapter examined and oftentimes rewritten to improve clarity, readability, and pedagogy–without sacrificing the breadth and depth of coverage that Electric Circuits is known for. Dr. Susan Riedel draws on her classroom experience to introduce the Analysis Methods feature, which gives students a step-by-step problem-solving approach.

1. Circuit Variables
2. Circuit Elements
3. Simple Resistive Circuits
4. Techniques of Circuit Analysis
5. The Operational Amplifier
6. Inductance, Capacitance, and Mutual Inductance
7. Response of First-Order RL and RC Circuits
8. Natural and Step Responses of RLC Circuits
9. Sinusoidal Steady-State Analysis
10. Sinusoidal Steady-State Power Calculations
11. Balanced Three-Phase Circuits
12. Introduction to the Laplace Transform
13. The Laplace Transform in Circuit Analysis
14. Introduction to Frequency Selective Circuits
15. Active Filter Circuits
16. Fourier Series
17. The Fourier Transform
18. Two-Port Circuits
Appendix A: The Solution of Linear Simultaneous Equations
Appendix B: Complex Numbers
Appendix C: More on Magnetically Coupled Coils and Ideal Transformers
Appendix D: The Decibel
Appendix E: Bode Diagrams
Appendix F: An Abbreviated Table of Trigonometric Identities
Appendix G: An Abbreviated Table of Integrals
Appendix H: Common Standard Component Values
